Basic Info.
| Load Capacity | 30T |
| Certification | ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949 |
| Wheel Base | 9000-10000mm |
| Tread | 2240mm |
| Grade | Heavy Duty |
| Types of Suspension Systems | Trailing Arm Type |
| Shape | Flatbed |
| Axle Number | 3 |
| Tire Number | 12 |
| Self-dumping | Self-dumping |
| ABS Anti-lock Braking System | ABS Anti-lock Braking System |
| Material | Aluminum |
| Specification | 11400*2550*3450 |
| HS Code | 8701200000 |
| Overall Dimension | 11500*2500*3800 |
| Tare weight | 10500kg |
| Tank body | Q235/4mm steel |
| End plate | Q235/6mm steel sheet |
| Axle | 3 axle 13T Fuwa Brand |
| suspension system | Mechanical suspension |
| steel spring | 10/10/10 leaf spring suspension |
| Manhole cover | 500mm manhole cover 8 sets |
| Tire | 12.00R20 12pcs |
| Rim | 9.0,12pieces |
| Discharge valve | 4″disc valve,8pcs |
| Discharge pipe | 4″seamless steel tube,8pcs |
| Spare wheel bracket | 2″bolt-in kingpin |
| Landing gear | fuwa brand two-speed, manual operating,28T |
| Tool box | one piece |
| Painting | complete chassis sand blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint |
| Main beams | opting for high tensile steel Q345B welded by automatic submerged-arc process |
| Electrical system | voltage:24v Reception:7 ways(7 wire harness) |
| Tail lamp with turn signal, brake light reflector, side lamp etc. | |
| one set 6-core standard cable |
PRODUCT DETAIL:
PRODUCT DESCRIPTION:
The semi-trailer oil tanker is a crucial and specialized vehicle in the petroleum transportation field. This particular semi-trailer oil tanker is crafted with meticulous attention to detail and advanced engineering techniques.
It is available in capacities of 35,000 liters and 45,000 liters, providing flexible options to suit different logistical requirements. The tank body is constructed using high-strength and corrosion-resistant materials, ensuring the safe and reliable containment of various types of oils during transit. The mirror face finish of the tanker not only gives it an eye-catching and sleek appearance but also offers enhanced protection against the elements, reducing the risk of rust and wear.
The trailer is designed with a stable and robust chassis structure, which can effectively withstand the heavy load and the rigors of long-distance transportation. Equipped with top-notch safety features such as reliable braking systems, emergency shut-off valves, and advanced leak detection mechanisms, it guarantees the utmost safety during the entire transportation process. The tanker also features convenient loading and unloading ports, enabling efficient and rapid transfer of the oil. Manufactured in our professional China factory, it adheres to strict international quality and safety standards. Our factory utilizes advanced production equipment and a highly skilled workforce to ensure the consistent high quality of each tanker. With its excellent performance and durability, this semi-trailer oil tanker is an ideal choice for oil companies, logistics providers, and other enterprises involved in the transportation and storage of petroleum products.
