Low Flatbed Semi-trailer Direct Sale from China Factory



Overall Dimension (mm) 11000,10500×3000×1750,3100,3300,3500
Total weight (Kg)  37000
Number of axles 3
Number of tires 12
  • Larger cargo space enables the transportation of a large amount of goods at one time.
  • The design without side panels can facilitate the loading and fixing of goods.

FEATURES

Product Details

Type Low-bed semi-trailer
Overall Dimension (mm) Length×width×height:11000,10500×3000×1750,3100,3300,3500
Total weight (Kg) 37000
Approach Angle/Departure Angle -/32,-/28
Front/rear suspension (mm) -/930,-/1050
Wheelbase (mm) 7300+1170+1170,6800+1170+1170,7180+1170+1170,6680+1170+1170
Axle Load -/21000(three axles)
number of axles 3
Number of spring pieces -/4/4/4,-/8/8/8
Number of tires 12
Tire Specifications 8.25R20 14PR,235/75R17.5 16PR
Front wheel base /
Rear wheel base 2180/2180/2180,2250/2250/2250,2330/2330/2330,2400/2400/2400
Others Only for the transport of non-detachable objects, the gooseneck part is not allowed to carry cargo. When the vehicle length is 11000mm, the corresponding relationship between dimensions (mm)/ wheelbase (mm)/ rear suspension (mm) is as follows :11000/7300+1170+1170/930,7180+1170+1170/1050; When the length is 10500mm, the corresponding relationship between dimensions (mm)/ wheelbase (mm)/ rear suspension (mm) is :10500/6800+1170+1170/930,6680+1170+1170/1050; Optional with a height of 1750mm without a ladder, body reflective signage has been installed on the sides and rear. Side protection material :Q235B, connection mode: bolt. Body parts replace the rear lower protection, the rear structure height from the ground :400mm.ABS system model :HNABS4S/4M,ABS system manufacturer: Liangshan Haina Electronic Technology Development Co., LTD.

    Message:

    Custom FAQs

    China sepcial truck is an enterprise with extensive influence and outstanding achievements in the field of special vehicles..We insists on supplying professional technology, high performance and good after-sale service to meet the requirements of customers from around the worlds. China Qigao will try our best to become your one-stop supplier. Name your detailed task and we will find a solution together!

    The types of special-purpose vehicles we export are extremely rich and varied, covering dump trucks, sprinkler trucks, oil tank trucks, advertising vehicles, engineering operation vehicles and many others. This wide range of products can fully meet the diverse needs of different customers.

    We have a strict quality control system. Every link from raw material procurement to production and processing is subject to strict inspection. At the same time, our vehicles have passed a series of international certifications, such as ISO quality system certification, etc., to ensure reliable product quality.

    We usually use sea transportation for shipping.  According to customer requirements, railway transportation or road transportation can also be selected. We will cooperate with professional logistics companies to ensure that vehicles are safely and timely delivered to destinations. function. What’s more, the plasma cutting also is available.

    Delivery time depends on multiple factors including vehicle model, order quantity, transportation method, etc. Generally speaking, it takes several months from signing the contract to delivering the vehicle. We will clearly specify the delivery time in the contract and do our best to complete the delivery according to the agreed time.
