Refrigerated Truck Frozen Food Transport Refrigerator ISUZU 4.2m Truck China factory Supplier

Overall Dimension (mm) 6000× 2500× 3300
Horsepower (Hp) 120
Fuel Diesel
Box Size (mm) 4100*2300*2100



FEATURES

Product Details

General Technical Parameters
Overall Dimension 6000×2500×3300(mm) Gross Vehicle Weight 9000(Kg)
Curb Weight 3900(Kg) Loading Weight 5000(Kg)
Chassis Specification
Chassis parameters Chassis Brand ISUZU
Cabin Single, Left Hand Driving, with A/C
Engine Model 4KH1-TCG4O, 4 Cylinders
Power 88KW/120HP
Emission standard EURO IV
Displacement 2.999L
Fuel type Diesel
Gearbox MSB, 5 Forward & 1 Reverse Gear
Front and Rear Axle load 2.5T/4.8T
Wheel base 3360(mm)
Overhang( Front/Rear) 1130/1505(mm)
Angle(Approach/departure) 20/16(°)
Brake System Oil brake
Steering Gear Power Assistant
Tire 650-16, 6 Pieces with 1 Spare Tire
Maximum speed 105(km/h)
Superstructure
Van Box size 4100×2300×2100(mm)
Material Fiberglass
Insulating Layer 8cm Polyurethane Foam
Brand THERMOKING
Truck refrigeration unit Model KV300
Applicable temperature (ºC) -18~0
Remarks Part Optional: Ventilation slot
Hook
External power supply
Side door

    Message:

    Custom FAQs

    China sepcial truck is an enterprise with extensive influence and outstanding achievements in the field of special vehicles..We insists on supplying professional technology, high performance and good after-sale service to meet the requirements of customers from around the worlds. China Qigao will try our best to become your one-stop supplier. Name your detailed task and we will find a solution together!

    The types of special-purpose vehicles we export are extremely rich and varied, covering dump trucks, sprinkler trucks, oil tank trucks, advertising vehicles, engineering operation vehicles and many others. This wide range of products can fully meet the diverse needs of different customers.

    We have a strict quality control system. Every link from raw material procurement to production and processing is subject to strict inspection. At the same time, our vehicles have passed a series of international certifications, such as ISO quality system certification, etc., to ensure reliable product quality.

    We usually use sea transportation for shipping.  According to customer requirements, railway transportation or road transportation can also be selected. We will cooperate with professional logistics companies to ensure that vehicles are safely and timely delivered to destinations. function. What’s more, the plasma cutting also is available.

    Delivery time depends on multiple factors including vehicle model, order quantity, transportation method, etc. Generally speaking, it takes several months from signing the contract to delivering the vehicle. We will clearly specify the delivery time in the contract and do our best to complete the delivery according to the agreed time.
