Mobile Digital LED Billboard Advertisement Diesel Engine ISUZU Truck Special Vehicle Made in China

Model Flat head, single row
LED screen size (mm) P6 panel (160*160)
Overall dimensions (mm) 5995×2040×2990



FEATURES

Product Details

Classification Item Unit Parameter
Vehicle Vehicle model ISUZU led advertising truck
Manufacturer
Overall dimensions mm 5995×2040×2990
Curb weight kg 4345
Traction system 4×2
Max speed km/h 98
Chassis Chassis model 10403HARY
Manufacturer
Number of axles 2
Wheel base mm 3360
Tire specification 7.00R15
Number of tires 6
F/R track base mm 1385 / 1425
Engine Engine model 4JB1CN
Manufacturer Isuzu (Chongqing) Engine Co., Ltd.
Fuel type Diesel
Power kw 72
Engine horse power hp 98
Displacement ml 2771
emission standard Euro IV
Driver’s cab Brand ISUZU
Model Flat head, single row
Allowable seats 3
Steering Left hand drive
Transmission 5-speed with over drive
Operation control system Electrically hydraulic control
Air-conditioning With air-conditioning
Standard equipment 1> Both sides (left and right) P6 waterproof full color led screen

2> The rear side monochrome screen to display the text;

3> 5cm composite steel box, wooden floor;

4> Inside and outside the electric distribution box;

5> Loop ventilation cooling system;

6> With 15KW Omar silent diesel generator;

7> One industrial computer with control system, 4 waterproof speakers, 1 amplifier, 1 console.

8> Left side screen with hydraulic lifting system, max 1.5m height.

9> Left side with a 9.6m2 hydraulic mobile stage.

LED screen size P6 panel (160*160 mm) Left and right: 3840*1728 mm
Color &Painting According to customer’s requirements



Product Description

1.It is equipped with an ultra-high-definition LED display, which can present extremely clear and delicate images and text content. Whether it’s colorful advertising videos, exquisite poster pictures or dynamic text information, all can be shown with the most perfect visual effects.

2.The system supports many common video formats such as MP4, AVI, MOV, etc., as well as picture formats (JPEG, PNG, etc.) and text formats (TXT, etc.), making it convenient for users to flexibly select and upload advertising materials according to their own needs.

3.Equipped with a professional-level audio system. The audio system uses high-fidelity speakers and has excellent sound quality restoration ability. Whether it is passionate music, clear voice narration or shocking sound effects, it can be played with the most real and full sound effect.

4.It has excellent mobility and flexibility. It can freely travel to every corner of the city, breaking through the geographical limitations of traditional fixed advertising spaces and accurately delivering advertising information to the target audience. Whether it’s bustling commercial centers, pedestrian streets with dense crowds, parking lots of large shopping malls, or various exhibition event sites, the surroundings of sports stadiums and so on, the advertising truck can easily reach these places and quickly carry out advertising and promotional activities.



F&Q

(1) What are the basic specifications of advertising trucks?

Our advertising trucks offer a variety of specification options. The body length is generally between 4 meters and 10 meters, the width is about 2 meters to 2.5 meters, and the height is around 2.5 meters to 4 meters. Specific dimensions can be customized according to customer needs. The interior space of the carriage is spacious and can accommodate advertising display equipment of different sizes and types, such as large LED displays and light boxes. The wheelbase and track width of the vehicle are carefully designed to ensure driving stability and handling flexibility, enabling smooth driving on both urban roads and rural paths.

(2) What kind of power system does the advertising truck use?

Foreign trade advertising trucks are equipped with multiple power systems to meet the needs of different countries and regions. Commonly, there are diesel engines, which have the characteristics of strong power and long cruising range, and are suitable for long-distance transportation and use in areas with relatively complete infrastructure and sufficient diesel supply. The power range varies from 80 kilowatts to 200 kilowatts, and can be selected according to the size and load requirements of the vehicle. In addition, we also offer electric power system options, which are more suitable for scenarios with high environmental protection requirements and short-distance urban operations. Electric advertising trucks use advanced lithium battery technology, with short charging time and a cruising range of up to 200 to 400 kilometers (the specific cruising range depends on battery capacity and usage environment), and have zero emissions and low noise during operation.

(3) What is the body material of advertising trucks? Is it durable?

The body of advertising trucks is a combination of high-quality steel and aluminum alloy materials. The main structure is made of high-strength steel to ensure the sturdiness and load-bearing capacity of the body, capable of withstanding the weight of advertising equipment and various stresses during driving. The outer shell is made of aluminum alloy material, which has the advantages of light weight and corrosion resistance. It not only helps improve the fuel economy (for diesel trucks) or cruising range (for electric vehicles), but also ensures that the body is not prone to rust and damage during long-term outdoor use. The surface of the body undergoes special anti-corrosion treatment and painting process, which can resist the erosion of natural environmental factors such as ultraviolet rays, rain, wind and sand, ensuring that the appearance of advertising trucks can still remain in good condition after many years of use.
