Technique parameters
Description | ||||
Chassis | Curb weight(kg) | 5495 | ||
G.V.W.(kg) | 7490 | |||
Wheelbase(mm) | 3800 | |||
Dimensions(mm) | 7420X2300X2540 | |||
Overhang (front/rear) (mm) | 1180/2440 | |||
Wheel track (front/rear) (mm) | 1835/1640 | |||
Approach/Departure angle(°) | 20/10 | |||
Max. driving speed(km/h) | 90 | |||
Brand | Dongfeng | |||
Model | EQ | |||
Tire | Number | 6+1pcs | ||
Specifications | 7.50R16 | |||
Clutch | Reinforced diaphragm clutch | |||
Gear box | 5 Forward & 1 reverse | |||
Front passenger | 2+1 | |||
Engine | Model | CY4102 | ||
Type | 4-stroke direct injection, 4cylinder in line with water cooling, turbo-charging and inter-cooling |
|||
Displacement(ml) | 3856 | |||
Power(kw) | 88 | |||
Emission standard | Euro 3 | |||
Brakes | Service brake: dual circuit compressed air brake Parking brake(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
|||
Steering Gear | Power steering, hydraulic steering with power assistance | |||
Fuel tank(L) | 180 | |||
Upper | ||||
Platform | L*W(mm) | 5400×2100 | ||
Platform power stroke(mm) | 2680 | |||
Min angle(°) | 7.6 | |||
Max lifting capacity(kg) | 3000 | |||
Winch rating pulling capacity(kg) | 4000 | |||
Length of steel(m) | 21 | |||
Hoisting | Max under-hoisting capacity(mm) | 1300 | ||
Rating under-hoisting capacity(mm) | 1005 | |||
Fully extended max under-hoisting capacity(mm) | 700 | |||
Rating under-pulling capacity(kg) | 6400 |
