Mobile Advertising Truck Outdoor Super Bright Display Dongfeng 4X2 LED Billboard Truck

Displacement 2.5L
LED Screen Type P6
LED Screen Waterproof, Shake-Proof, High Brightness
Floor Aluminum Patterned Floor





FEATURES

Product Details

Product Info.

General Technical Parameters
Overall Dimension 5990×1990×2950(mm)
Gross Vehicle Weight 4495(Kg)
Curb Weight 4365(Kg)
Chassis Specification
Chassis parameters Chassis Brand Dongfeng
Cabin Single, Left Hand Driving, with A/C
Engine Model 4 Cylinders
Power 70KW/95HP
Emission standard EURO III
Displacement 2.771L
Fuel type Diesel
Gearbox 5 Forward & 1 Reverse Gear
Front and Rear Axle load 2T/4 T
Wheel base 3300(mm)
Overhang( Front/Rear) 1015/1620(mm)
Angle(Approach/departure) 24/12 (°)
Brake System Oil brake
Steering Gear Power Assistant
Tire 700-16, 6 Pieces with 1 Spare Tire
Maximum speed 90(km/h)
Superstructure
LED Screen Pixel Outdoor full colour display screen

P6

Dimension(LxW)(mm) Both side: 3840*1792

Rear:1280*1440

Description Screen lift on both sides

Waterproof, shake-proof, high brightness, long life

General configuration 1. Silent diesel generator, 15KW

2. One set industrial computer with control system

3. Sound system: Loudspeaker 4pcs, amplifier 1pc

4. Internal and external electrical distribution box.

5. Circulating ventilation and cooling systems.

6. 5CM composite steel frame body

7. Aluminum patterned floor

Remarks Equipped with Hydraulic stage

The color of the superstructure is oprional.

    Message:

    Custom FAQs

    China sepcial truck is an enterprise with extensive influence and outstanding achievements in the field of special vehicles..We insists on supplying professional technology, high performance and good after-sale service to meet the requirements of customers from around the worlds. China Qigao will try our best to become your one-stop supplier. Name your detailed task and we will find a solution together!

    The types of special-purpose vehicles we export are extremely rich and varied, covering dump trucks, sprinkler trucks, oil tank trucks, advertising vehicles, engineering operation vehicles and many others. This wide range of products can fully meet the diverse needs of different customers.

    We have a strict quality control system. Every link from raw material procurement to production and processing is subject to strict inspection. At the same time, our vehicles have passed a series of international certifications, such as ISO quality system certification, etc., to ensure reliable product quality.

    We usually use sea transportation for shipping.  According to customer requirements, railway transportation or road transportation can also be selected. We will cooperate with professional logistics companies to ensure that vehicles are safely and timely delivered to destinations. function. What’s more, the plasma cutting also is available.

    Delivery time depends on multiple factors including vehicle model, order quantity, transportation method, etc. Generally speaking, it takes several months from signing the contract to delivering the vehicle. We will clearly specify the delivery time in the contract and do our best to complete the delivery according to the agreed time.
